Recessed Lighting
Architectural LED Downlights

Star

need assistance on this product? call us now 01582 369 005

Description

For comfortable yet focused lighting, the Star mini architectural LED downlights model is available in four lens angles to achieve a narrow to broad spread of light. Whether it’s architectural lighting or task lighting, this range offers warm light from high-power, high-efficiency LEDs.

The Star LED downlight is available in multiple baffle colour variations, colour temperatures and CRI to ensure minimum glare,  emitting healthy workplace lighting all while complementing your project interior. Whether you’re looking to achieve UGR<19 or UGR<12, this product will enable your vision rather than limit it.

Key Features

  • Advanced LED engine
  • Bezel in RAL9003 white
  • Anti-glare baffles with UGR<19 when white and UGR<12 when black
  • Wide choice of options and accessories
  • Emergency, DALI dimming and Casambi wireless control options
  • CRI>95
  • Fire-rated
  • Adjustable version available (Star Tilt)
  • 5-year warranty
  • Manufactured in UK

Star



The Blaze mini linear downlight is available with 5 or 10 lenses and various beam angles. The fittings are available with a choice of wireless, dimming and emergency functionalities and with various coloured baffles and trims to choose from the Blaze is the ideal high-end solution to your lighting project.

,

Star

DOWNLOAD DATASHEET
Enquire today
Product Code LED Wattage Lumen Output Lumen/Watt Colour Temperature Beam Angle
STR10 10W 1000 100 4000K 38°
STR12 12W 1200 100 4000K 38°

Product Options

Section Option Code Description
1 – Emergency No emergency, leave blank
/M 3 Hour Maintained Emergency
/MZ 3 Hour DALI Maintained Emergency
2 – Control /ND Non Dimmable Driver
/DALI DALI/DSI Dimmable Driver
/BTC Casambi Dimmable
3 – Bezel /WH White RAL9003
4 – CCT /4K 4000K
/3K 3000K
/27K 2700K
5 – Lens /15 15° lens
/24 24° lens
/38 38° lens
/60 60° lens
6 – CRI /95 CRI >95
7 – Baffle /WH White Baffle
/BK Black Baffle
/GL Gold Baffle
/SL Silver Baffle
