The CBU-PWM4 is a Casambi-enabled dimmer designed for constant voltage LED loads, including LED strips and constant voltage LED modules. It functions as an
regulator between a 12-24v DC power supply and the LED load.
With the ability to manage up to four channels, the CBUPWM4 is a perfect fit for RGBW and tunable white (TW) applications. The maximum total output current is 6A, which can be divided among the four channels as needed. The CBU-PWM4 is protected against short circuits, overvoltage, and overcurrent situations, but not
against reverse polarity.
Different fixture profiles can be loaded on the PWM4 for different functionality.
No downloads available.
| Product Code | Colour | Dimensions |
|---|---|---|
| CBU-PWM4 | White | 72.6mm × 30mm × 18mm |
| Technical Specifications | Details |
|---|---|
| Input Power | 12-24V DC, max 6A |
| Max Output Power | 144W @ 24V, 72W @ 12V. Output voltage is the same as input voltage |
| Dimming Method | Pulse Width Modulation (PWM) |
| Radio Operation Frequencies | 2400-2480 MHz |
| Wireless Range | Up to 30m inside, up to 50m outside |
| Ambient Temperature | -20°C to +45°C |
| Cable – Solid/Stranded | 0.75 – 1.5mm², strip length 7mm |
| Weight | 23g |
| Ingress Protection | IP20 |
