CBU-TED is an innovative trailing-edge phase-cut dimmer designed to cater to your specific lighting needs. It is compatible with incandescent lamps, dimmable LED lamps, and dimmable LED control gear. You can install it behind a conventional wall switch, inside a luminaire, or into a ceiling outlet box. It is essential to adhere to the maximum allowable ambient temperature to ensure optimal performance.
With a capacity to control up to 100W at 230v AC, CBU-TED comes with overcurrent and overtemperature protection features. You can conveniently manage it with the Casambi app, available on iOS and Android devices.
No downloads available.
| Product Code | Colour | Dimensions |
|---|---|---|
| CBU-TED | White | 40.4mm × 36.3mm × 14.0mm |
| Technical Specifications | Details |
|---|---|
| Input | 85-240V AC, 50-60 Hz |
| Output | 0.43A, 100W at 240V AC |
| Max Inrush Current | 10A, 100ms |
| Dimming Method | Trailing edge phase cut |
| Radio Operation Frequencies | 2400-2480 MHz |
| Wireless Range | Up to 30m inside, up to 50m outside |
| Ambient Temperature | -20°C to +45°C |
| Cable – Solid Core | 0.5 – 1.5mm², strip length 6-8mm |
| Weight | 15g |
| Ingress Protection | IP20 |
