Xpress-LR is a wireless, long-range, Casambi-enabled, user interface that brings huge flexibility to interior design, as furniture can be replaced and walls can be
rebuilt without having to take the wiring of switches or switch placement into account. The switch can be kept wherever the user needs it and it gives direct access to all the important Casambi lighting control functionalities.
There are different radio modes that can be selected when creating a network in the Casambi App: ‘Balanced’, ‘Better Performance’ and now ‘Long Range’ options. The Xpress-LR enables long-range capabilities only when the long-range radio mode has been selected and all the other devices within the network are long-range capable.
It will revert to the shorter, standard range when deployed in networks set to ‘Balanced’ or ‘Better Performance’ modes.
No downloads available.
| Product Code | Colour | Dimensions |
|---|---|---|
| CBU-XPRESS-LR | White/Black | 90mm × 90mm × 12mm |
| Technical Specifications | Details |
|---|---|
| Voltage | 3V DC |
| Battery Type | CR2430 Lithium Coin Cell |
| Radio Operation Frequencies | 2402-2480 MHz |
| Maximum Output Power | +8 dBm |
| Ambient Temperature | 0°C to +40°C |
| Max Humidity | 0 – 80%, non-condensing |
| Weight | 72g |
| Ingress Protection | IP20 |
