M-Line Low Glare Recessed Trimless Lighting is a great solution for creating a finish that is almost completely smooth to the surface it’s installed within. With standard lengths of 2824mm available and bespoke lighting design formations and lengths available to order, the Low Glare Recessed Trimless M-Line lighting system can be used for everything from delicate projects to larger fit-outs requiring strong downlighting performance.
Although the standard system is designed for ceiling mounting, wall-mounted versions can be supplied on request where this better suits your design. With a simple clip-in fitting, installation is fast and efficient, helping you save time on any project with the M-Line system.
| Low Glare Recessed Trimless Lighting System | |||||
| Product Code | LED Wattage | Lumen Output | Lumen/watt | Colour Temp. | Size |
| MLGT568 | 13W | 1337 | 102 | 4000K | 568 x 50mm |
| MLGT848 | 19W | 2005 | 106 | 4000K | 848 x 50mm |
| MLGT1128 | 24W | 2673 | 110 | 4000K | 1128 x 50mm |
| MLGT1408 | 30W | 3341 | 112 | 4000K | 1408 x 50mm |
| MLGT1688 | 35W | 4010 | 114 | 4000K | 1688 x 50mm |
| MLGT1968 | 41W | 4678 | 115 | 4000K | 1968 x 50mm |
| MLGT2248 | 46W | 5346 | 116 | 4000K | 2248 x 50mm |
| MLGT2528 | 52W | 6014 | 116 | 4000K | 2528 x 50mm |
| MLGT2808 | 57W | 6683 | 118 | 4000K | 2808 x 50mm |
| Section | Option Code | Description |
|---|---|---|
| 1 – EMERGENCY | Leave blank if no emergency | |
| /M | Emergency | |
| /MZ | DALI Emergency | |
| 2 – CONTROL | /ND | Non Dim |
| /DA | DALI Dim | |
| /BTC | Casambi Dim | |
| /2DA | Dual Channel DALI Dim | |
| /2BTC | Dual Channel Casambi Dim | |
| 4 – CCT | /4K | 4000K |
| /3K | 3000K (light output -6%) | |
| 5 – CRI | /80 | CRI>80 (typical 84) |
| /90 | CRI>90 |
