The 48v low voltage LED track light fittings include pendants and linear lights in a variety of sizes and are specially designed to discreetly conceal the control gear for use with our Stucchi-compatible Multi-Track LV system.
The extruded aluminium housings are available in black as a standard or white option. With two colour temperatures and two CRI options to choose from, you can guarantee the perfect light for the right scene.
Adding re-positionable pendants and linear area/task light fittings to your track lighting makes the full gamut of Mount Lighting’s wide style range available on one highly controllable system. Track Lighting is no longer limited to spots!
| Product Code | LED Wattage |
Lumen Output |
Lumen/ Watt |
Colour Temp. |
Beam Angle |
| Linear – Opal | |||||
| TRL285/6/BLK | 6W | 865 | 144 | 4000K | |
| TRL570/11.9/BLK | 11.9W | 1730 | 145 | 4000K | |
| TRL850/17.8/BLK | 17.8W | 2590 | 146 | 4000K | |
| Linear – Lensed | |||||
| TRLL285/5.6/BLK | 5.6W | 640 | 114 | 4000K | 30° |
| TRLL570/10.2/BLK | 10.2W | 1280 | 125 | 4000K | 30° |
| TRLL850/15.2/BLK | 15.2W | 1920 | 126 | 4000K | 30° |
| Cylinder | |||||
| TRC50/3/BLK | 3W | 480 | 160 | 4000K | 25° |
| TRC50/4.4/BLK | 4.4W | 670 | 152 | 4000K | 25° |
| Circle Pendant | |||||
| TRCP400/22.6/BLK | 22.6W | 3140 | 139 | 4000K | |
| Section | Option Code | Description |
|---|---|---|
| 1 – CONTROL | /ND | Non Dim |
| /DA | DALI Dim | |
| /BTC | Casambi Dim | |
| 2 – FINISH | /9005 | RAL9005 Black |
| /9016 | RAL9016 White | |
| 3 – CCT | /4K | 4000K |
| /3K | 3000K | |
| 4 – BEAM ANGLE | /20 | 20° Linear Lensed |
| /26X42 | 26×42° Linear Lensed | |
| 5 – CRI | /80 | CRI>80 |
| /90 | CRI>90 |
