Description

Low Glare lighting is popular throughout all commercial offices where lighting has a focus on the people working under them. Whether it’s for maintaining CIBSE levels or blowing away clients the moment they walk through the door, low glare linear lighting is a dynamic way to introduce height and levels into a room while utilising direct and indirect lighting elements within the same linear lighting profile, for the perfect task and ambient light.

For simple, clean runs of low glare light that fully illuminate office and commercial spaces, our M-Line low glare lighting systems are available in standard lengths up to 2808mm. Custom lengths for continuous lighting systems are available to order in 140mm increments and bespoke geometric-shaped feature lights with fully illuminated corners can be created upon request.

Surface mounting is achieved by directly fixing through the rear of the profile. The suspension is made simple using a single-point ceiling bracket with 2m adjustable stainless steel wire system. For additional spreads of light or to create bold focal points, uplighting is available on lengths from 568mm upwards.

No matter the application, the low glare M-Line system will provide up to 118 lumen output and comfortable lighting wherever it is used. This clean, refined luminaire option will ensure that any application stands out while maintaining a well-constructed, impressive visual as standard.

Key Lighting Features

  • Aluminium extruded sections in 10 standard lengths
  • Bespoke lengths available in 47/140mm increments
  • Upto 121 lm/W, 138 lm/W for direct/indirect
  • Colour options in 3000K and 4000K
  • Custom lengths and shapes available subject to design
  • Incorporates Tridonic/Helvar LED drivers
  • Direct/Indirect lighting options available for suspended fittings
  • Utilises latest generation long-life LEDs from leading manufacturers
  • Clip-in gear tray for easy installation
  • Low glare dual lens diffuser
  • Tuneable white and RGB options available
  • Dimmable and emergency options available
  • Compatible with Casambi wireless control system
  • Dual Control option available
  • CRI>80, >100,000h life expentancy
  • 5-year warranty
  • Made in Britain

Suspended Direct Lighting System
Product Code LED Wattage Lumen Output Lumen/watt Colour Temp. Size
MLGE568 13W 1337 102 4000K 568 × 50mm
MLGE848 19W 2005 106 4000K 848 × 50mm
MLGE1128 24W 2673 110 4000K 1128 × 50mm
MLGE1408 30W 3341 112 4000K 1408 × 50mm
MLGE1688 35W 4010 114 4000K 1688 × 50mm
MLGE1968 41W 4678 115 4000K 1968 × 50mm
MLGE2248 46W 5346 116 4000K 2248 × 50mm
MLGE2528 52W 6014 116 4000K 2528 × 50mm
MLGE2808 57W 6683 118 4000K 2808 × 50mm
NOTE: Includes 2m suspension kits (longer bespoke lengths available in 140mm increments)
Surface Mount Lighting System
Product Code LED Wattage Lumen Output Lumen/watt Colour Temp. Size
MLGS568 13W 1337 102 4000K 568 × 50mm
MLGS848 19W 2005 106 4000K 848 × 50mm
MLGS1128 24W 2673 110 4000K 1128 × 50mm
MLGS1408 30W 3341 112 4000K 1408 × 50mm
MLGS1688 35W 4010 114 4000K 1688 × 50mm
MLGS1968 41W 4678 115 4000K 1968 × 50mm
MLGS2248 46W 5346 116 4000K 2248 × 50mm
MLGS2528 52W 6014 116 4000K 2528 × 50mm
MLGS2808 57W 6683 118 4000K 2808 × 50mm
Suspended Direct/Indirect Lighting System / 50% Direct • 50% Indirect
Product Code LED Wattage Lumen Output Lumen/watt Colour Temp. Size
MLGD568 21W 2553 124 4000K 568 × 50mm
MLGD848 29W 3830 130 4000K 848 × 50mm
MLGD1128 38W 5107 133 4000K 1128 × 50mm
MLGD1408 47W 6383 134 4000K 1408 × 50mm
MLGD1688 56W 7660 136 4000K 1688 × 50mm
MLGD1968 65W 8937 137 4000K 1968 × 50mm
MLGD2248 74W 10213 137 4000K 2248 × 50mm
MLGD2528 86W 11490 134 4000K 2528 × 50mm
MLGD2808 95W 12767 134 4000K 2808 × 50mm
NOTE: Includes 2m suspension kits (longer bespoke lengths available in 140mm increments)

Section Option Code Description
1 – EMERGENCY Leave blank if no emergency
/M Emergency
/MZ DALI Emergency
2 – CONTROL /ND Non Dim
/DA DALI Dim
/BTC Casambi Dim
/2DA Dual Channel DALI Dim
/2BTC Dual Channel Casambi Dim
3 – FINISH /9016 RAL9016 White
/9005 RAL9005 Black
/RA Any RAL Colour
4 – CCT /4K 4000K
/3K 3000K (light output -6%)
5 – CRI /80 CRI>80 (typical 84)
/90 CRI>90
